Threaded collars
Internal pistion threads |
|
Order
No. |
Cyl.
Cap.
(tons)* |
Stroke
(in.) |
Re-
tracted
Height
(in.) |
Oil
Cap.
(cu.in.) | |
| C51C |
5 |
1 |
4(3/8) |
1.1 |
| C53C |
5 |
3(1/4) |
6(1/2) |
3.2 |
| C55C |
5 |
5(1/4) |
8(1/2) |
5.2 |
| C57C |
5 |
7(1/4) |
10(3/4) |
7.2 |
| C59C |
5 |
9(1/4) |
12(3/4) |
9.2 |
| C101C |
10 |
1 |
3(5/8) |
2.2 |
| C102C |
10 |
2(1/8) |
4(3/4) |
4.8 |
| C104C |
10 |
4(1/8) |
6(3/4) |
9.2 |
| C106C |
10 |
6(1/8) |
9(3/4) |
13.7 |
| C108C |
10 |
8(1/8) |
11(3/4) |
19.9 |
| C1010C |
10 |
10(1/8) |
13(3/4) |
22.6 |
| C1012C |
10 |
12(1/8) |
15(3/4) |
27.1 |
| C1014C |
10 |
14(1/8) |
17(3/4) |
31.6 |
| C151C |
15 |
1 |
4(7/8) |
3.1 |
| C152C |
15 |
2(1/8) |
5(7/8) |
6.7 |
| C154C |
15 |
4(1/8) |
7(7/8) |
12.9 |
| C156C |
15 |
6(1/8) |
104(11/16) |
19.2 |
| C158C |
15 |
8(1/8) |
12 |
25.5 |
| C1510C |
15 |
10(1/8) |
14 |
31.8 |
| C1512C |
15 |
12(1/8) |
16 |
38.1 |
| C1514C |
15 |
14(1/8) |
18 |
44.4 |
| C1516C |
15 |
16 |
20 |
50.3 |
| C251C |
25 |
1 |
5 |
5.1 |
| C252C |
25 |
2 |
6 |
10.3 |
| C254C |
25 |
4 |
8 |
20.6 |
| C256C |
25 |
6(1/4) |
10 |
32.2 |
| C258C |
25 |
8(1/4) |
12 |
42.5 |
| C2510C |
25 |
10(1/4) |
14 |
52.8 |
| C2512C |
25 |
12(1/4) |
16 |
63.2 |
| C2514C |
25 |
14(1/4) |
18 |
73.5 |
| C552C |
55 |
2 |
6 |
22.1 |
| C554C |
55 |
4(1/4) |
9 |
46.9 |
| C556CL† |
55 |
6 |
12 |
66.3 |
| C556C |
55 |
6(1/4) |
11 |
69.0 |
| C5510C |
55 |
10(1/4) |
15 |
113.2 |
| C5513C |
55 |
13(1/4) |
18 |
146.3 |
| C756C |
75 |
6(1/4) |
12 |
97.4 |
| C7513C |
75 |
13(1/4) |
19 |
208.7 |
| C1002C |
100 |
2 |
8 |
41.2 |
| C1006C |
100 |
6(5/8) |
13 |
137.0 |
| C1006CL† |
100 |
6(1/4) |
14 |
128.9 |
| C10010C |
100 |
10(1/4) |
16 |
211.5 |
| C1506CL† |
150 |
6 |
15 |
184.1 |
| † With Steel locking collar |
